Stationary tribune with a riser, type TSH-350-Omega - for indoor use

14-80-Omega
VAT included

TSH-350-Omega sports tribune with plastic seats, platforms made of anti-slip plywood, risers made of steel sheets, adjustable feet, powder coated steel structure

Quantity
mail_outline Ask a question

Stationary tribune with a riser, type TSH-350-Omega - for indoor use


Intended: for indoor use


Basic features of the system:
  • Certificate of compliance with EN-PN 13200 standards
  • Steel structure, powder coated
  • Modern design and high aesthetic
  • Individual design - the ability to adapt to each facility
  • Safe platforms made of anti-slip plywood
  • Risers made of steel sheet

Material and technical specification:

Axial spacing of seats 500 mm
Type of seats Two-piece gravity-tilting OMEGA chairs with backrest ~ 37 cm
Level difference between platforms 350 mm
The height of the middle steps 175 mm
Steps finishing Aluminum safety angles with a rubber (anti-slip) insert
The width of the entrances >120 cm
Metal surfaces finishing Powder coating by the RAL palette
As a standard light gray RAL 7035
Railings colour As a standard RAL 7035 or in the colour of the structure
Material of the platform Anti-slip board 18 mm thick
Material of the risers Steel sheet 1.5 mm thick
Maximum loading According to the standard PN-EN 13200-1

The number of rows / Parameters 2 3 4 5 6 7 8
The depth of the tribune [cm] 130 200 270 340 410 480 550
The height of the last platform [cm] 35 70 105 140 175 210 245
Average number of seats per 1 m * ~3,5 ~5 ~6,5 ~8 ~9,5 ~11 ~12,5

* Average number of seats listed in the table may differ from the actual value in the finished project, due to local conditions, layout of seats, number of entrances, etc.

General information
Stationary tribune for indoor use, with plastic seats, riesers made of steel sheets and platforms made of anti-slip plywood.

The structure of the tribune is made of closed steel profiles (transverse frames, connectors, brackets for attaching seats) and hot rolled metal sheets 1.5 mm thick, bent in a special shape, powder coated to any color in the RAL palette (as a standard RAL 7035 – light gray). The frames are mounted in standard spacing of 2000 m or 1500 mm.

The tribune is equipped with durable, ergonomic, double-layer Omega chairs with a gravity-folding seat and a contoured, high backrest. The double-walled backrest and seat not only guarantee the chair's high durability but also provide insulation, ensuring the user's comfort while watching the sporting event.

The design of the tribune is customize for particular facility, according to the safety directives concerning tribunes.


Length of the tribune - depending on the required number of seats and rows, or conditioned by restrictions in the development of the area.

In order to obtain full information, please contact the Technical and Trade Department.
