With its own technological line for surface preparation and coating application, PESMENPOL has control over the quality of the finish and corrosion protection of the components of the produced sports equipment and tribunes. As a result, the company also offers a variety of steel substrate protection variants and a wide range of available colours for both indoor and outdoor sports equipment.


As standard, the steel structural elements of produced sports equipment intended for indoor use are protected against corrosion by abrasive blasting and powder coating (corrosion class C1), while for sports equipment used outdoors, the steel structure is subjected to abrasive blasting and hot-dip galvanizing and optionally powder coated (corrosion class C4). Other finishing options are also available upon individual request. The developed technology allows, among others, for the use of double anti-corrosion protection. This is a method of protecting steel elements with a zinc coating and an external powder coating. Prior cleaning of the surface of the components in the abrasive blasting process ensures that the appropriate roughness is obtained to increase the adhesion of the coatings, while the cleaning in the chemical treatment process and the created passive layer provide an additional protective barrier to environmental factors. Powder coating of hot-dip galvanized elements is recommended in the case of high levels of corrosion factors, and at the same time allows obtaining attractive colors of the processed sports equipment used outdoors. The powder coating protects the hot-dip galvanized surface from environmental and chemical influences, prevents rusting under the coating and enhances edge protection. By protecting against zinc removal, it extends the service life of the product protected in this way.

The tables below present the range of available solutions within the PESMENPOL PROTECT technology.



Structures of sports equipment and tribunes for indoor use
Corrosivity class (acc. to EN ISO 12944-1) Examples of environment in temperate climate (for information only) Type of steel surface protection (PESMENPOL PROTECT system)
C1 – insignificant Heated buildings with clean atmosphere, e.g. shops, offices, etc. mechanical pretreatment in grade SA 2½ or SA 3 * + chemical pretreatment (conversion coating) + top coat of 80 μm polyester powder paint – STANDARD
C2 – low Non-heated buildings with condensation, e.g. sports arenas, warehouses, etc. mechanical pretreatment in grade SA 2½ or SA 3 * + chemical pretreatment (conversion coating) + zinc flakes containing / zinc flake free powder primer 60 μm + top coat of 80 μm polyester powder paint
C3 – medium Production facilities with increased humidity and moderate pollution, e.g. breweries, laundries, creameries and dairies, etc.
C4 – high Chemical plants, swimming pools, shipyards mechanical pretreatment in grade SA 2½ or SA 3 * + chemical pretreatment (conversion coating) + 2 layers of zinc flakes containing / zinc flake free powder primer 60 μm + top coat of 80 μm polyester powder paint


Structures of sports equipment and tribunes for outdoor use
Corrosivity class (acc. to EN ISO 12944-1) Examples of environment in temperate climate (for information only) Type of steel surface protection (PESMENPOL PROTECT system)
C2 – low Atmosphere with low level of pollution, mostly rural areas mechanical pretreatment in grade SA 2½ or SA 3 * + chemical pretreatment (conversion coating) + top coat of 80 μm polyester powder paint
C3 – medium Urban and industrial atmosphere, moderate Sulphur dioxide pollution; coastal areas with low salinity mechanical pretreatment in grade SA 2½ or SA 3 * + chemical pretreatment (conversion coating) + zinc flakes containing / zinc flake free powder primer 60 μm + top coat of 80 μm polyester powder paint
C4 – high Industrial zones and coastal areas with moderate salinity

mechanical pretreatment in grade SA 2½ or SA 3 *+ hot-dip galvanizing acc. to EN ISO 1461 - STANDARD

or

mechanical pretreatment in grade SA 2½ or SA 3 * + chemical pretreatment (conversion coating) + zinc flakes containing / zinc flake free powder primer 60 μm + top coat of 80 μm polyester powder paint

C5-I – very high (industrial) Industrial zones with damp conditions and aggressive atmosphere mechanical pretreatment in grade SA 2½ or SA 3 * + hot-dip galvanizing acc. to EN ISO 1461 + mechanical pretreatment (sweeping) + chemical pretreatment (conversion coating) + zinc flakes containing / zinc flake free powder primer 60 μm + top coat of 80 μm polyester powder paint
C5-M – very high (marine) Inshore and offshore areas with intense salty atmosphere

* depending on the product
